Mingjiada supplies Power MOSFET IRF3808STRRPBF IRF3808 N-channel surface mount type 75 V 106A, new and original, in stock, welcome to contact us if you are interested.
Model No: IRF3808STRRPBF
Batch number: 11+
Package: TO-263
Description: MOSFET N-CH 75V 106A D2PAK
Advantage
Advanced process technology
Ultra-low on-state resistance
Dynamic dv/dt rating
175°C operating temperature
Fast switching
Repeated avalanches allowed up to Tjmax
Lead free
Property parameters
Product Type: MOSFET
Technology: Si
Mounting Style: SMD/SMT
Package / Case: TO-252-3
Transistor polarity: N-Channel
Number of Channels: 1 Channel
Vds - drain-source breakdown voltage: 75 V
Id-Continuous drain current: 106 A
Rds On - drain-source on-resistance: 7 mOhms
Vgs - Gate-source voltage: - 20 V, + 20 V
Vgs th - gate source threshold voltage: 4 V
Qg - gate charge: 150 nC
Minimum operating temperature: - 55 C
Maximum operating temperature: + 175 C
Pd - power dissipation: 200 W
Channel mode: Enhancement
Configuration: Single
Descent time: 120 ns
Forward transconductance - min: 100 S
Height: 2.3 mm
Length: 6.5 mm
Rise time: 140 ns
Typical close delay time: 68 ns
Typical turn-on delay time: 16 ns
Typical Applications
Industrial automotive
