Mingjiada supplies Hexagonal Half Bridge Driver IC TLE84106 TLE84106EL for automotive motion control applications, new and original, welcome to contact.
The TLE84106EL is a protected hexagonal half-bridge driver designed for automotive motion control applications such as heating, ventilation and air conditioning (HVAC) flap DC motor control. It is part of the MonolythIC family Infineon's Smart Power Technology SPT® which combines bipolar and CMOS control circuits with DMOS power supplies.
Model: TLE84106EL
Year: 13+
Package: SSOP
Type: Power Management (PMIC)
Specification
Output configuration Half Bridge (6)
Application DC motors, general purpose
Interface SPI
Load type Inductive
Technology DMOS
On-resistance (typical) 800 milliohm LS, 800 milliohm HS
Current - Output/Channel -
Current - Peak Output -
Voltage - Supply 3V ~ 5.5V
Voltage - Load 7V ~ 18V
Operating Temperature -40°C ~ 150°C (TJ)
Features -
Fault Protection Open Load Detect, Over Temperature, Short Circuit, UVLO
Mounting Type Surface Mount Type
Package/Case 24-LSSOP (0.154", 3.90mm wide) Exposed Pad
Supplier Device Package PG-SSOP-24-4
