Mingjiada supplies the new and original Li-Ion LTC4065 LTC4065LXEDC LTC4065LXEDC#TRPBF Battery Charger with 2×2 DFN
The LTC4065L is a complete constant current/voltage linear charger for single-cell Li-ion batteries. the LTC4065L is small in size and can precisely regulate low charge currents, making it particularly suitable for portable applications using low-capacity rechargeable Li-ion batteries. In addition, the LTC4065L is specifically designed for use with USB power specifications.
Brand: LT
Model: LTC4065LXEDC LTC4065LXEDC#TRPBF
Lot Number: 10+
Package: DFN
Features
Charge current programmable up to 250mA with 5% accuracy
Complete linear charger in 2mm x 2mm DFN package
C/10 charge current detection output
Timer termination
No external MOSFETs, sense resistors or blocking diodes required
Preset floating voltage with 0.6% accuracy.
-LTC4065L/LTC4065LX at 4.2V
-4.1V for LTC4065L-4.1/LTC4065LX-4.1
Constant current/constant voltage operation
Thermal feedback to maximise charge rate
No risk of overheating
Charge current monitor output for gas measurement
Automatic recharge
Charging of single-cell Li-ion batteries directly from the USB port
20µA supply current in shutdown mode
No trickle charge available (LTC4065LX/LTC4065LX-4.1)
Miniature 6-lead (2mm x 2mm) DFN package
Applications
Wireless PDAs
Mobile phones
Portable electronics
