Mingjiada supplies the ON NCS199A3SQT2G NCS199A3 Current Sense Amplifier 1 Circuit Full swing, the NCS199A3 is a voltage output current shunt monitor that measures the voltage of the shunt at common mode voltages from -0.3 V to 26 V, independent of the supply voltage.
These devices can operate from a single supply of +2.7 V to +26 V and can draw a maximum supply current of 100 A. All versions are specified over an extended operating temperature range (-40°C to +125°C).
Product type: NCS199A3SQT2G
Batch size: 1736+
Package: SC70-6
Condition: New and original stock
Amplifier Type: Current Sensing
Number of circuits: 1
Output type: Full swing
Slew rate: 0.4V/µs
-3db Bandwidth: 40 kHz
Current - input bias: 60 µA
Voltage - input compensation: 5 µV
Current - supply: 65 µA
Voltage - Span (min): 2.7 V
Voltage - Span (max): 26 V
Operating Temperature: -40°C ~ 125°C
Mounting Type: Surface Mount Type
Package/Housing: 6-TSSOP, SC-88, SOT-363
Supplier Device Packages: SC-88/SC70-6/SOT-363
Typical Applications
- Current sensing (high-side/low-side)
- Automotive
- Telecom
- Sensors
