Mingjiada supplies Logic Gate 74LVC1G08 74LVC1G08GW Gate and Inverter 1-channel 5-TSSOP, new and original, please contact us if you are interested.
The 74LVC1G08 is a high performance, low power, low voltage silicon gate CMOS device, superior to the most advanced CMOS compatible TTL family. The inputs can be driven by 3.3 V or 5 V devices. These features allow the use of these devices in mixed 3.3 V and 5 V environments. The Schmitt trigger action for all inputs gives the circuit a slow input rise and fall time. The device is fully suitable for partial input power off applications using Ioff. The Ioff circuit disables the output to prevent destructive return currents through the device when it is powered off. 74LVC1G08 provides a single 2 input and function.
Product Attributes
Manufacturer: Nexperia
Product Type: Logic Gate
Product: Single-Function Gate
Logic Function: AND
Logic Family: 74LVC
Number of Gates: 1 Gate
Number of Input Lines: 2 Input
Number of output lines: 1 Output
High level output current: - 32 mA
Low level output current: 32 mA
Propagation delay time: 5.5 ns
Supply voltage - max: 5.5 V
Supply voltage - min: 1.65 V
Minimum operating temperature: - 40 C
Maximum operating temperature: + 125 C
Mounting Style: SMD/SMT
Package / Case: TSSOP-5
Function: AND
Height: 1 mm
Length: 2.2 mm
Logic type: AND Gate
Operating supply voltage: 1.65 V to 5.5 V
Product type: Logic Gates
Static current: 100 nA
Factory Pack Quantity: 3000
Sub Category: Logic ICs
Width: 1.35 mm
Unit weight: 23 mg
