Supply Electronics Chip NCP160AMX280TBG NCP160 PMIC - Linear Regulator Output Current 250mA

Mingjiada presents the new original ON NCP160AMX280TBG NCP160 PMIC - Linear Regulator, LDO Regulator for RF and Analog Circuits - Ultra Low Noise and High PSRR.

Supply Model: NCP160AMX280TBG
Brand: ON
Batch: 1814+
Package: 4XDFN
Status: New and original stock
Product type:Low dropout voltage regulator
Mounting Style:SMD/SMT
Package / Case: XDFN-4
Output voltage: 2.8 V
Output current: 250 mA
Number of outputs: 1 Output
Polarity: Positive
Static current: 18 uA
Input voltage (min.): 1.9 V
Input voltage (max): 5.5 V
PSRR / Ripple Rejection - typical: 48 dB
Output type: Fixed
Min. operating temperature: - 40 C
Max. operating temperature: + 125 C
Return voltage: 95 mV
Series: NCP160
Return voltage - max: 160 mV
Line regulation: 0.02 %/V
Load regulation: 0.001 %/mA

The ON Semiconductor NCP160 LDO regulator is a linear regulator that provides up to 250mA of output current. These LDO regulators use 1µF input and 1µF output ceramic capacitors. The ON Semiconductor NCP160 regulators offer high efficiency at light load conditions and low power consumption at full load. Other features include low noise, high PSRR, low quiescent current and excellent load/line transients. These regulators are ideally suited for use in power sensitive and noise sensitive devices as well as space constrained applications. These devices are available in an ultra-small 0.35P (0.65mm x 0.65mm) chip-scale package (CSP) and XDFN-4 0.65P (1mm x 1mm) package.

Applications
Battery powered devices
Wireless LAN devices
Smartphones and tablets
Cameras, DVRs, STBs and all-in-one recorders
