[Supply FPGA Chip] Xilinx XC7K70T-2FBG484I High-Performance Field-Programmable Gate Array

Mingjiada Electronics supplies Xilinx XC7K70T-2FBG484I FPGA chip product description:

The XC7K70T-2FBG484I is a high-performance field-programmable gate array (FPGA) chip from Xilinx (now part of AMD) within the Kintex®-7 series, featuring a 484-BBGA package. It is specifically designed for applications requiring high bandwidth, low power consumption, and flexible programmability. As one of Mingjiada Electronics' core supply products, this device has broad application prospects in fields such as communications, industrial automation, and high-performance computing.

Core Features

High-Performance Logic Architecture

Provides 65,600 logic elements (LE) and 5,125 configurable logic blocks (CLB), supporting complex digital circuit design.

Includes 144GMACS of digital signal processing (DSP) capability, suitable for high-speed signal processing tasks such as wireless communication baseband processing.

High-Speed Serial Communication Capability

Supports 8-channel PCI Express Gen1/Gen2, providing an efficient host system connectivity solution.

Peak serial bandwidth up to 800Gbps (full-duplex), suitable for distributed baseband architectures and high-speed data exchange.

Optimised storage resources

Integrated 4,976,640-bit Block RAM to meet large data buffering and storage requirements.

Supports multiple storage interface configurations, including DDR3/4, QDR II+, etc.

Low-power design

Utilises 28nm process technology to deliver high performance while maintaining low power consumption.

Dynamic power optimisation technology, suitable for portable devices and energy-efficient applications.

Rich I/O interfaces

Provides 285 programmable I/O pins, supporting multiple voltage standards (LVDS, HSTL, SSTL, etc.).

Suitable for high-speed ADC/DAC interfaces, memory connections, and system-level interconnections.

XC7K70T-2FBG484I Product Attributes

Product Type: FPGA - Field-Programmable Gate Array

Series: XC7K70T

Number of Logic Elements: 65,600 LE

Adaptive Logic Modules (ALM):    10,250 ALM

Embedded Memory:    4.75 Mbit

Number of Input/Output Ports:    285 I/O

Minimum Power Supply Voltage:    970 mV

Supply Voltage - Maximum:    1.03 V

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +100°C

Data Rate:    12.5 Gb/s

Number of Transceivers:    4 Transceivers

Mounting Style:    SMD/SMT

Package/Case:    FCBGA-484

Distributed RAM:    838 kbit

Embedded Block RAM - EBR:    4860 kbit

Maximum Operating Frequency:    640 MHz

Number of Logic Array Blocks - LAB:    5125 LAB

Operating Power Supply Voltage:    1.2 V to 3.3 V

Typical Application Scenarios

5G Communication Equipment: Used for LTE/WiMAX baseband processing and optical module control.

Industrial Automation: Servo control, machine vision, PLC logic control.

Medical Electronics: Portable ultrasound devices, medical imaging systems.

Aerospace: Avionics systems, radar signal processing.

Consumer Electronics: LED backlight control, 3D TV signal processing.

For more detailed technical specifications or purchasing support, please contact Mingjiada Electronics (Phone: +86 13410018555 / E-mail: sales@hkmjd.com / Homepage: www.mjdic.com).
