ST STM32G030C8T6TR 64MHz 32-Bit Single-Core Embedded MCU



Shenzhen Mingjiada Electronics Co., Ltd., as a seasoned supplier in the electronic components industry, has been consistently supplying ST's STM32G030C8T6TR microcontroller. This STM32G030C8T6TR, a 32-bit MCU based on the ARM® Cortex®-M0+ core, stands out for its high performance, low power consumption, and high integration, making it an ideal choice for consumer electronics, industrial control, and IoT applications.



Product Overview and Core Technology Of STM32G030C8T6TR

The STM32G030C8T6TR is a mainstream value-for-money series microcontroller, packaged in an LQFP-48 package, with a maximum operating frequency of 64MHz, perfectly balancing performance and cost requirements. As a 32-bit single-core embedded microcontroller, the STM32G030C8T6TR is based on the ARM Cortex-M0+ RISC core and uses the efficient Thumb®/Thumb-2 instruction set, delivering exceptional processing power while maintaining low power consumption.



The STM32G030C8T6TR device features 64KB of flash program memory and 8KB of SRAM, supports operation over a wide temperature range from -40°C to 85°C, and is compatible with power supply voltages from 2V to 3.6V, making it particularly suitable for battery-powered devices. The STM32G030C8T6TR's Memory Protection Unit (MPU) enhances system security, while the Direct Memory Access (DMA) controller significantly improves data transfer efficiency and reduces CPU load.



The STM32G030C8T6TR boasts impressive peripheral integration, including:

19-channel 12-bit ADC: supports high-precision analogue signal acquisition

Multiple communication interfaces: including I2C, IrDA, LINbus, SPI, UART/USART, etc.

Rich timer resources: PWM, watchdog timer (WDT), power-on reset (POR), etc.

43 programmable I/O pins: providing flexible hardware connectivity capabilities



These features make the STM32G030C8T6TR an ideal choice for applications such as home appliance control, industrial sensor nodes, consumer electronics, and simple IoT terminals. Its compact package size (7x7mm LQFP) is also suitable for space-constrained design scenarios.





Specification Of STM32G030C8T6TR

Core Processor：ARM® Cortex®-M0+

Core Size：32-Bit Single-Core

Speed：64MHz

Connectivity：I2C, IrDA, LINbus, SPI, SmartCard, UART/USART

Peripherals：DMA, I2S, POR, PWM, WDT

Number of I/O：43

Program Memory Size：64KB (64K x 8)

Program Memory Type：FLASH

RAM Size：8K x 8

Voltage - Supply (Vcc/Vdd)：2V ~ 3.6V

Data Converters：A/D 19x12b

Oscillator Type：External, Internal

Operating Temperature：-40°C ~ 85°C (TA)



Performance Ddvantages And Application Areas Of STM32G030C8T6TR

The STM32G030C8T6TR achieves an excellent balance between performance and power consumption. Its 64MHz clock speed, combined with the efficient Cortex-M0+ core, enables it to handle most embedded control tasks while maintaining low power consumption. This characteristic makes it particularly suitable for the following application areas:



1. Smart Home and Consumer Electronics

Home appliance control boards: Main control units for appliances such as washing machines, air conditioners, and microwave ovens

Smart remote controls: Low-power human-machine interface devices supporting multiple communication protocols

Small display devices: Electronic price tags, simple information displays, etc.



2. Industrial Automation

Sensor nodes: Data acquisition and processing for industrial sensors such as temperature, humidity, and pressure

Small motor control: Basic control applications for stepper motors and DC motors

HMI panels: Simple human-machine interface control



3. IoT terminal devices

Edge nodes: IoT terminals for data collection and preliminary processing

Wireless module coprocessors: Local control units that work with wireless communication modules

Battery-powered devices: Suitable for portable devices that need to run for a long time thanks to their low power consumption
