Supply TI Isolator——Original ISO7220CDR Dual Channel Digital Isolator
Shenzhen Mingjiada Electronics Co., Ltd.——Long-term supply of TI (ISO7220CDR) based on capacitive isolation technology designed dual-channel digital isolator, optimised for high-noise industrial environments that require signal isolation and level shifting applications.
Product Details:
[ISO7220CDR] Dual-channel digital isolator with logic input and output buffers to block high voltages and isolate grounds, and to prevent noise currents on data buses or other circuits from going to local ground or interfering with or damaging sensitive circuits.The ISO7220CDR requires two 2.8V (Class C), 3.3V, or 5V power supplies, or any of these power supplies. The ISO7220CDR requires two 2.8V (Class C), 3.3V, 5V supplies or any combination of these. All inputs are 5V tolerant and all outputs are 4mA CMOS when powered from 2.8V or 3.3V supplies.
Package: SOIC-8
Type: Digital Isolator
ISO7220CDR Product Diagram:
ISO7220CDR Product Attributes:
Technology: Capacitive Coupling
Type: General Purpose
Isolated Power Supply: None
Number of Channels: 2
Inputs - Side 1/Side 2: 2/0
Channel Type: Unidirectional
Voltage - Isolation: 2500Vrms
Common Mode Transient Immunity (min): 25kV/µs
Data Rate: 25Mbps
Propagation Delay tpLH / tpHL (max): 42ns. 42ns
Pulse Width Distortion (Max): 2ns
Rise/Fall Time (Typ): 1ns, 1ns
Voltage - Supply: 2.8V ~ 5.5V
Operating Temperature: -40°C ~ 125°C
Mounting Type: Surface Mount
Package/Case: 8-SOIC
ISO7220CDR Applications:
Factory Automation
- Modbus
- Profibus™
- DeviceNet™ Data Bus
Computer Peripheral Interface
Server Control Interface
Data Acquisition
[Mingjiada Electronics] Long term supply ISO7220CDR, for Isolator ISO7220CDR specifications, sample request or price inquiry, welcome to contact Mingjiada Electronics:
