[Supply Sensor] Mingjiada Electronics Supply LIS2DH12TR——High Performance 3-Axis Linear Accelerometer
Product Description:
The LIS2DH12TR is an ultra-low power, high performance triaxial linear accelerometer belonging to the ‘femto’ series with digital I2C/SPI serial interface standard output.
The LIS2DH12TR has a user-selectable full scale of ±2g/±4g/±8g/±16g and is capable of measuring acceleration at output data rates from 1 Hz to 5.3 kHz.
The LIS2DH12TR can be configured to generate an interrupt signal by detecting two independent inertial wake-up/free-fall events as well as the position of the device itself.
The LIS2DH12TR is available in a small, thin plastic grid array package (LGA) that guarantees operation over a wide temperature range of -40 °C to +85 °C. The LIS2DH12TR is also available in a low-profile, low-profile, low-cost package.
LIS2DH12TR Product Features:
Wide supply voltage, 1.71 V to 3.6 V
Independent IO power supply (1.8 V), supply voltage compatible
Ultra-low power consumption down to 2 μA
±2g/±4g/±8g/±16g Selectable full scale
I2C/SPI digital output interface
2 independent programmable interrupt generators for free-fall and motion detection
6D/4D direction detection
Free-fall detection
Motion detection
Embedded temperature sensor
Embedded FIFO
LIS2DH12TR Specifications:
Type: Digital
Axis: X, Y, Z
Acceleration Range: ±2g, 4g, 8g, 16g
Sensitivity (LSB/g): 1000 (±2g) ~ 83 (±16g)
Bandwidth: 0.5Hz ~ 672Hz
Output Type: I2C, SPI
Voltage - Supply: 1.71V ~ 3.6V
Characteristics: Adjustable Bandwidth, Selectable Range. Sleep Mode, Temperature Sensor
Operating Temperature: -40°C ~ 85°C
Mounting Type: Surface Mount
Package/Housing: 12-VFLGA
Supplier Device Package: 12-LGA (2x2)
