Mingjiada Supply [TI] ADS1115IDGSR 16-bit Low Power Precision Analog-To-Digital Converter (ADC)
Shenzhen Mingjiada Electronics Co., Ltd.——Long-term supply of TI (ADS1115IDGSR) low-power, 16-bit Δ-Σ analog-to-digital converter (ADC), VSSOP-10 package, I2C-compatible, the device has a wide range of operating supply voltages, and therefore is very suitable for power-constrained and space-constrained sensor measurement applications. power-constrained and space-constrained sensor measurement applications.
Mingjiada Supplies——TI ADS1115IDGSR 16-bit Analog-to-Digital Converter (ADC)
Product Details:
The ADS1115IDGSR is an ultra-small, low-power, 860SPS, 16-bit, low-power, precision analog-to-digital converter (ADC) with an internal reference, oscillator, and programmable comparator, and is I2C-compatible. ADC). The device features a low-drift voltage reference and oscillator, and includes a programmable gain amplifier (PGA) and a digital comparator.
Package: VSSOP-10
Type: Analog-To-Digital Converter (ADC)
Product Diagram:
ADS1115IDGSR: 4 single-ended inputs or 2 differential inputs with comparator and PGA
Wide Supply Voltage Range: 2.0V to 5.5V
Low Current Consumption: 150µA (Continuous Conversion Mode)
Programmable Data Rate: 8SPS to 860SPS
Single-Cycle Stabilisation
Internal Low-Drift Voltage Reference
Internal Oscillator
I2C Interface: four pin selectable addresses
Operating Temperature Range. Operating temperature range: -40°C to +125°C
Typical application scenarios for the ADS1115IDGSR:
Portable Instrumentation
Battery Voltage and Current Monitoring
Temperature Measurement Systems
Consumer Electronics
Factory Automation and Process Control
The ADS1115IDGSR has a data conversion rate of up to 860 samples per second (SPS), and the PGA provides an input range from ±256mV to ±6.144V for accurate small and large signal measurements. The device features an input multiplexer (MUX) for dual differential input or quad single-ended input measurements.
【Mingjiada Electronics】Long-term supply of TI (ADS1115IDGSR) 860SPS, 4-channel 16-bit Δ-Σ analogue-to-digital converter (ADC), for more information about the analogue-to-digital converter ADS1115IDGSR product information or to consult the price, welcome to visit the official website of the Mingjiada Electronics (www.mjdic.com) to find out more.
