Mingjiada Electronics: Supply (Renesas) RZ Series High Performance MPU, Supply RZ Series 32-Bit MPU, 64-Bit MPU
Shenzhen Mingjiada Electronics Co., Ltd. has been providing Renesas with a full range of high-performance microprocessor (MPU) products for a long time. We especially focus on supplying RZ series 32-bit MPUs and 64-bit MPUs, which are ideal for industrial automation, AI edge computing, network communication, human-machine interface (HMI), motor control, etc. due to their excellent performance, rich function integration, powerful real-time processing capability and optimised design for different application scenarios.
Mingjiada Electronics can stably supply the following Renesas RZ series sub-series and their representative models (please consult Mingjiada Electronics for specific model supply):
1. RZ/V Series: Edge AI MPUs for AI Vision Processing
Core Features: Integrated with Renesas' exclusive DRP-AI (Dynamically Reconfigurable Processor) accelerator, designed for low-power, high-efficiency real-time AI vision processing (e.g., target detection, image recognition). Typically equipped with powerful ARM Cortex-A cores (e.g. A55/A53) and image processing units (ISPs).
Representative models:
RZ/V2L (Dual-core Cortex-A55 + DRP-AI + ISP) - Popular entry-level AI vision MPU
RZ/V2M (Dual-core Cortex-A53 + DRP-AI + ISP + 3D GPU) - Higher performance with 3D graphics support
RZ/V3U (Quad-core Cortex-A55 + Dual DRP-AI + powerful ISP + GPU) - Flagship AI vision processing performance
Main applications: AI cameras, smart retail devices, service robots, security surveillance, defect detection, portable medical devices.
2. RZ/A Series: MPUs with large-capacity on-chip RAM, no external DRAM required
Core Features: The biggest advantage is the integration of ultra-large-capacity on-chip SRAM (up to 10MB), which significantly simplifies the system design (eliminating the need for external DRAM), reduces the cost, and improves startup speed and reliability. Based on ARM Cortex-A core (e.g. A9).
Representative models:
RZ/A1H (Single-core Cortex-A9, 10MB RAM)
RZ/A1L (Single-core Cortex-A9, 3MB RAM)
RZ/A2M (Single-core Cortex-A9, 10MB RAM + 2D Graphics Accelerator) - Enhanced Graphics Processing
RZ/A3UL (Dual-core Cortex-A55, 1.5MB RAM + optional DRAM support) - New generation, higher performance
Main Applications: Human Machine Interface (HMI), industrial control panels, home appliance control, portable devices, embedded systems that require fast startup and reliability.
3. RZ/T Series: High-performance real-time control MPU
Core Features: Adopts a unique Asymmetric Multi-Processing (AMP) architecture, which integrates ARM Cortex-R cores for real-time control (e.g., R4F) and ARM Cortex-M cores for application processing (e.g., M4/M33) on the same chip and interconnects them via a high-speed bus. Powerful motor control peripherals (e.g. encoder interface, high-precision PWM) and real-time accelerators are integrated.
Representative models:
RZ/T1 (Dual-core Cortex-R4F + Cortex-M3)
RZ/T2M (Dual-core Cortex-R52 + Cortex-M33) - new generation, higher real-time performance and safety
RZ/T2L (Single-core Cortex-R52 + Cortex-M33) - cost/performance optimised version
Main applications: high-end servo drives, industrial robots, CNC machines, inverters, complex motion control requiring ultra-low latency and hard real-time response. 4.
4. RZ/G Series: Processing Platforms for High Performance Linux Applications
Core Features: Based on high performance ARM Cortex-A cores (e.g. A57/A53 combo, A55), providing powerful general-purpose computation and graphics processing capabilities (integrated GPU). Supports rich interfaces and high-speed connectivity (e.g., PCIe, USB 3.0, GbE), long-term supply commitment (LTS), and is designed to run complex operating systems such as Linux.
Representative models:
RZ/G1H (Quad-core Cortex-A15 + Cortex-A7 + GPU)
RZ/G1N (Dual-core Cortex-A57 + Quad-core Cortex-A53 + GPU)
RZ/G1E (Single-core Cortex-A7 + GPU) - Entry-level Linux MPU
RZ/G2L (Dual-core Cortex-A55 + single-core Cortex-M33 + GPU) - cost-effective, balanced performance and power consumption
RZ/G2UL (single- or dual-core Cortex-A55 + Cortex-M33 + GPU) - ultra-low-power Linux MPU
RZ/G3S (single-core Cortex-A55 + dual-core Cortex-M33 + GPU) - low-power performance with Security Island
Main Applications: Industrial Human Machine Interface (HMI), medical equipment, high-end gateways, printers, digital signage, robot controllers.
5. RZ/N Series: Industrial Network Communication MPUs
Core Features: Integrated high-performance communication engine and industrial Ethernet protocol accelerators (e.g. EtherCAT, PROFINET, EtherNet/IP, TSN, etc.) to ensure high-precision, low-latency network communication. Based on ARM Cortex core (e.g. A7, R7, R52), providing reliable real-time performance.
Representative models:
RZ/N1S (Dual-core Cortex-R7 + Cortex-M3 + Dual Gigabit Ethernet + TSN/Industrial Protocol Acceleration)
RZ/N2L (Single-core Cortex-R52 + Gigabit Ethernet + TSN/Industrial Protocol Acceleration) - Cost-effective network endpoint solution
Main applications: Industrial Ethernet switches, gateways, programmable logic controllers (PLCs) Industrial Ethernet switches, gateways, programmable logic controllers (PLCs), remote I/O, fieldbus master/slave, networked industrial equipment.
For product information of Renesas RZ series high-performance MPUs or to inquire about product price, please contact Mingjiada Electronics:
