Automotive Connectors - PL00Y-301-10M10 Amphenol PowerLok™ Single-pole high-voltage Socket

Mingjiada Electronics offers genuine, in-stock automotive connectors — PL00Y-301-10M10 Amphenol PowerLok™ single-pole high-voltage socket, specifically designed for EV/HEV and energy storage systems

Product Description

PL00Y-301-10M10 is a single-pole high-voltage female connector from the Amphenol PowerLok™ series, featuring a Y-Key anti-misinsertion design and a metal housing, providing reliable busbar connections for electric vehicles, hybrid vehicles, and energy storage systems under high vibration, high impact, and harsh temperature and humidity conditions, supporting 300 A high current and 1000 V DC high voltage.

Applications:

The POWERLOK G2 series is a high-performance, compact aluminium alloy connection solution featuring RADSOK contact technology, specifically designed for electric vehicles (EVs) and hybrid transportation applications. The G2 series offers electrical ratings of up to 1000 VDC and 450 A (at 50°C ambient temperature), featuring an IP67/9K sealing rating, 360° shielding, multiple keyed options, right-angle and straight configurations, and up to three positions. The G2 series can be used as field-assembled connectors, supporting shielded cable cross-sections from 50mm² to 120mm². The POWERLOK G2 series connectors are designed for diverse application scenarios, including power distribution systems for automobiles, trucks, buses, agricultural machinery, construction equipment, and off-road vehicles.

Core Features

• Rated current: 300 A (single pole)

• Rated voltage: 1000 V DC

• 1-core female socket with Y-Key anti-misinsertion coding to prevent incorrect insertion

• Metal housing + IP67 protection rating, waterproof and dustproof

• High-voltage interlock (HVIL) function to enhance system safety

• Full temperature range operation from -40 °C to +125 °C

• Compatible with large cable diameters from 35 mm² to 70 mm², with crimping or screw mounting options

• ≥500 insertion/removal cycles, low contact resistance ≤0.2 mΩ

• Compliant with RoHS, REACH, and UL94-V0 flame retardant requirements

PL00Y-301-10M10 Specifications:

Rated Voltage: 1000 V DC

Rated current: 100A

Withstand voltage test: 5000V DC

Operating temperature: -40°C to +125°C

Protection rating: IP67

Contact type: Female, straight

Installation method: Panel mount or harness connection

Compliance standards: RoHS environmental compliance
