Mingjiada Electronics Supply TI ISO7221CDR 25Mbps Digital Isolator (SOIC-8)
Shenzhen Mingjiada Electronics Co., Ltd.——As a leading electronic component supplier, has been supplying (TI) ISO7221CDR - 25Mbps Digital Isolator for a long time. The ISO7221CDR is designed for high-speed signal isolation in a SOIC-8 package for use in harsh industrial environments.
The ISO7221CDR features logic input and output buffers that are isolated by TI's Silicon Dioxide (SiO2) barrier, providing VDE-compliant galvanic isolation up to 4000 VPK. The ISO7221CDR requires two 2.8V (Class C), 3.3V, 5V power supplies, or any combination of these. All inputs are 5V tolerant and all outputs are 4mA CMOS when powered from 2.8V or 3.3V supplies.
ISO7221CDR Product Features:
1Mbps, 5Mbps, 25Mbps, and 150Mbps Signalling Rate Options
Low Channel Output Skew; 1ns maximum
Low Pulse Width Distortion (PWD); 1ns maximum
Low Jitter Content; 1ns typical at 150Mbps
50kV/µs Typical Transient Immunity
From 2.8V (Class C), 3.3V or 5V supply
4kV ESD protection
High electromagnetic immunity
Operating temperature range -40°C to +125°C
Service life at rated voltage 28 years typical
ISO7221CDR Specifications:
Technology: Capacitive Coupling
Type: General Purpose
Isolated Power Supply: None
Number of Channels: 2
Inputs - Side 1/Side 2: 1/1
Channel Type: Unidirectional
Voltage - Isolated: 2500Vrms
Common Mode Transient Immunity (min): 25kV/µs
Data Rate: 25Mbps
Propagation Delay tpLH / tpHL (max): 42ns, 42ns Pulse Width Distortion (max). 42ns
Pulse Width Distortion (Max): 2ns
Rise/Fall Time (Typ): 1ns, 1ns
Voltage - Supply: 2.8V ~ 5.5V
Operating Temperature: -40°C ~ 125°C
Mounting Type: Surface Mount
Package/Housing: 8-SOIC (0.154", 3.90mm wide)
ISO7221CDR Applications:
- Factory Automation
- Modbus
- Profibus™
- DeviceNet™ data buses
- Computer Peripheral Interface
- Server Control Interface
- Data Acquisition
【Mingjiada Electronics】Long-term supply of TI (ISO7221CDR) 25Mbps digital isolator, such as obtaining more information about the ISO7221CDR products or consulting price, welcome to contact Mingjiada Electronics:
