Bosch BMI055 Ultra-small 6-axis Inertial Sensor - Mingjiada Stock Inventory, Genuine Original Product

Bosch BMI055 6-axis inertial sensor — Mingjiada Electronics has it in stock, genuine factory product, supporting small batch samples to large volume purchases

The Bosch BMI055 is an ultra-compact 6-axis inertial measurement unit (IMU) that integrates a 12-bit three-axis accelerometer and a 16-bit three-axis gyroscope, packaged in a 3.0×4.5×0.95mm³ LGA-16 package. It is specifically designed for high-precision motion detection applications such as smartphones, wearable devices, game controllers, and drones.

Bosch BMI055 Core Advantages

• Dual-sensor fusion: Simultaneously detects acceleration (±2g to ±16g) and angular velocity (±125°/s to ±2000°/s), enabling 6-degree-of-freedom (6DoF) motion tracking

• Ultra-low power consumption: Accelerometer operating current as low as 130µA, sleep mode <1µA, ideal for battery-powered devices

• High precision and low noise: Accelerometer zero offset error ±70 mg, gyroscope noise density 0.1 mdps/√Hz

• Industrial-grade reliability: Supports operating temperatures from -40°C to +85°C, resistant to mechanical shocks and electromagnetic interference

• Flexible interfaces: Supports I²C (400 kHz) and SPI (10 MHz), compatible with mainstream embedded platforms

Bosch BMI055 Product Highlights

• 6 DoF integration: 3-axis ±16 g accelerometer + 3-axis ±2000 °/s gyroscope

• Miniature packaging: 3 mm × 4.5 mm × 0.95 mm LGA-14, suitable for space-constrained designs

• Low power consumption: 5 mA in normal mode, 5 µA in sleep mode, extending battery life

• High bandwidth: 1 kHz ODR for accelerometer, 2 kHz ODR for gyroscope, accurately capturing impacts and vibrations

• Digital interface: I²C/SPI dual bus, with built-in 32-level FIFO buffer

• Industrial-grade temperature range: –40 °C to +85 °C

 Bosch BMI055 Typical Applications

• Consumer electronics: smartphone screen rotation, AR/VR head tracking, gaming motion control

• Drones/robots: flight attitude stabilisation, robotic arm motion detection

• Health monitoring: smart bracelet gait analysis, fall detection

• Industrial automation: vibration monitoring, equipment status sensing

Purchase inquiries: +86 13410018555 (Mr. Chen)

Email: sales@hkmjd.com

Website: www.mjdic.com

For detailed specifications or quotes, please contact Mingjiada Electronics!
