Mingjiada Electronics Supply TI TLV3541IDBVR Operational Amplifier: SOT-23 (DBV)-5, 200MHz, Single Channel
Shenzhen Mingjiada Electronics Co., Ltd.——Long-term stable supply of Texas Instruments (TI) original chip TLV3541IDBVR single-channel, low-power, rail-to-rail output CMOS operational amplifier. This high-performance device is available in a miniature SOT-23-5 package, and its design is optimised for battery-powered and low-voltage applications, providing excellent performance at very low quiescent current.
Product Description
TI's TLV3541IDBVR is a single-channel operational amplifier that offers an excellent balance of speed, power consumption and output range. Its 200MHz bandwidth, 400V/µs slew rate, rail-to-rail output capability, and low power consumption make it a powerful solution for driving ADCs, building high-speed filters, processing sensor signals, and more.
TLV3541IDBVR Key Specifications
Number of Circuits: 1
Output Type: Full Swing
Voltage Slew Rate: 150V/µs
Gain Bandwidth Product: 100 MHz
-3db Bandwidth: 200 MHz
Current - Input Bias: 3 pA
Voltage - Input Compensation: 2 mV
Current - Supply: 5.2 mA
Current - Outputs/Channels: 100 mA
Voltage - Span (min.): 2.5 V
Voltage - Span (max.): 5.5 V
Operating Temperature: -40°C ~ 125°C
Mounting Type: Surface Mount
Package/Case: SC-74A. SOT-753
Supplier Device Package: SOT-23-5
TLV3541IDBVR Product Features
Wide Bandwidth Amplifier for Cost-Sensitive Systems
Unit Gain Bandwidth: 200MHz
High Conversion Rate: 150V/µs
Low Noise: 7.5 nV/√Hz
Rail-to-Rail I/O
High Output Current: > 100mA
Excellent Video Performance:
Differential Gain: 0.02%, Phase Difference: 0.09°
0.1dB Gain Flatness: 40MHz
Low input bias current: 3pA
Quiescent current: 5.2mA
Thermal shutdown
Power supply range: 2.5V to 5.5V
TLV3541IDBVR Typical Applications
With its low power consumption and small size, the TLV3541IDBVR is widely used in:
Portable/battery-powered devices: Hand-held instruments, medical sensors, remote controls, wearable devices.
Sensor signal conditioning: temperature sensors (e.g. thermocouples, RTDs), pressure sensors, photodiode amplifiers.
Active Filtering: Low power low pass, high pass, band pass filters.
Supply Current Monitoring: Amplification of small voltages across shunt resistors in battery management systems.
Low Power Comparators: Replacement of specialised comparators where response times are not critical.
Industrial Control Systems: 4-20mA transmitters, PLC analogue input modules (low voltage section).
Consumer electronics: mobile phone accessories, portable audio equipment front-end amplification.
