Mingjiada Electronics Supply TI LM53601MQDSXRQ1 Automotive Synchronous Buck Regulator
Product Description
The LM53601MQDSXRQ1 is a synchronous step-down (buck) DC-DC converter designed for harsh automotive environments. It integrates a high-efficiency power MOSFET in a compact VQFN package and operates at switching frequencies up to 2.1MHz, and is designed to efficiently step down nominal 12V automotive battery input voltages, typically in the range of 3.5V to 36V, to lower voltages, providing a stable and reliable power supply for a wide range of on-board electronic systems. The LM53601MQDSXRQ1's core strength is its synchronous rectification architecture, which significantly improves conversion efficiency and reduces external component count.
Output Type: Adjustable
Number of Outputs: 1
Voltage - Input (min): 3.8V
Voltage - Input (max): 36V
Voltage - Output (min/fixed): 3.3V
Voltage - Output (max): 6V
Current - Output: 1A
Frequency - Switch: 2.1MHz
Synchronous Rectifier: Yes
Operating Temperature: -40°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package/Case: 10-WFDFN Unpadded
Supplier Device Package: 10-WSON (3x3)
LM53601MQDSXRQ1 Product Features
High switching frequency (2.1MHz): Allows the use of smaller external inductors and capacitors, resulting in significant board space savings and optimised overall solution size.
Integrated power MOSFETs: Built-in high-side and low-side MOSFET switches simplify design and reduce bill-of-material (BOM) cost and complexity.
Automotive-grade reliability: The LM53601MQDSXRQ1 is AEC-Q100 Grade 1 compliant, ensuring stable operation under the extreme temperature, voltage fluctuation, and vibration conditions of automotive applications.
Thermally Enhanced Package: The VQFN package provides low thermal resistance for improved heat dissipation.
Soft-start: Integrated soft-start function limits inrush current during startup, protecting the input power supply and back-end circuits.
Enable Control (EN): Provides shutdown control to reduce standby power consumption.
LM53601MQDSXRQ1 Applications
Thanks to its wide input voltage range, high efficiency, compact size and high reliability, the LM53601MQDSXRQ1 is an ideal power supply for many automotive electronic systems:
Automotive Camera Applications
Automotive Driver Assistance Systems
Automotive Body Applications
