ST STM32H730ZBT6 High-Performance STM32H7 550MHz ARM Cortex-M7 32-Bit MCU



Shenzhen Mingjiada Electronics Co., Ltd., a globally renowned distributor of electronic components, has been supplying the STM32H730ZBT6 microcontroller. This is a high-performance 32-bit MCU based on the 550MHz ARM Cortex-M7 core, designed for demanding applications such as industrial automation, artificial intelligence edge computing, and high-end consumer electronics.



STM32H730ZBT6 Description

The STM32H730ZBT6 device is based on a high-performance Arm® Cortex®-M7 32-bit RISC core, operating at a maximum frequency of 550 MHz. The Cortex®-M7 core is equipped with a floating-point unit (FPU), supporting Arm® double-precision (compliant with the IEEE 754 standard) and single-precision data processing instructions and data types. The Cortex-M7 core includes 32 KB of instruction cache and 32 KB of data cache. The STM32H730ZBT6 device supports a full DSP instruction set and a memory protection unit (MPU) to enhance application security.



The STM32H730ZBT6 device integrates high-speed embedded memory, including 128 KB flash, up to 564 KB RAM (of which 192 KB can be shared between ITCM and AXI, plus 64 KB dedicated to ITCM, plus 128 KB dedicated to AXI, 128 KB DTCM, 48 KB AHB, and 4 KB backup RAM), as well as a rich set of enhanced I/O and peripherals connected via the APB bus, AHB bus, two 32-bit multi-AHB bus matrices, and multi-layer AXI interconnects supporting both internal and external memory access. To enhance application robustness, all memory supports error correction codes.





STM32H730ZBT6 Core Features

The STM32H730ZBT6 belongs to STMicroelectronics' STM32H7 series of high-performance microcontrollers, representing the highest performance level of Cortex-M core MCUs currently available. The STM32H730ZBT6 device is manufactured using STMicroelectronics' advanced 40nm process and integrates multiple innovative technologies to achieve breakthrough processing capabilities.



Ultra-high-performance processing core:

Features a 550MHz ARM Cortex-M7 core with support for a double-precision floating-point unit (FPU) and DSP instruction set

Equipped with STMicroelectronics' proprietary ART Accelerator™ technology, enabling zero-wait-state execution with processing performance up to 1327 DMIPS/3224 CoreMark

Includes 16KB instruction cache (I-Cache) and 16KB data cache (D-Cache), significantly enhancing real-time performance



High-capacity, efficient storage system:

On-chip integration of 128KB Flash memory and 564KB SRAM (including 128KB DTCM RAM for critical real-time data)

Supports external memory interfaces, enabling connection to NOR Flash, SRAM, SDRAM, etc., to expand storage capacity

Dual-bank Flash architecture supports in-application programming (IAP), enabling firmware updates without downtime



Rich peripheral interfaces:

Up to 168 GPIO pins with support for various multiplexing function configurations

High-speed communication interfaces: USB 2.0 OTG (full-speed/high-speed), 4x SPI (up to 100MHz), 4x I2C, 3x USART/UART, 2x CAN FD

Analogue interfaces: 3 12-bit ADCs (16 channels, 2.5 MSPS), 2 12-bit DACs

Graphics acceleration: Chrom-ART accelerator enhances GUI performance, supports LCD-TFT controller



Advanced security features:

Hardware encryption engine (AES-128/256, HASH, RSA, ECC)

Secure boot and secure firmware update (SFU) functionality

Memory protection unit (MPU) and firewall mechanism

Unique device identifier (UID) for anti-cloning protection



Energy-efficient design:

Multiple low-power modes: sleep, stop, standby, shutdown

Dynamic voltage regulation function, adjusting core voltage based on workload

Typical operating current: 400µA/MHz (operating mode), as low as 5µA in shutdown mode



STM32H730ZBT6 Target Application Areas

Industrial Automation and Control Systems:

High-performance PLCs and motion controllers

Industrial HMIs and touchscreen devices

Real-time predictive maintenance systems

High-precision motor drive control



Artificial Intelligence and Edge Computing:

Localised AI inference devices

Computer vision processing terminals

Smart sensor data fusion

Speech recognition and natural language processing



Consumer Electronics and Multimedia:

High-end smart home appliance control

Virtual Reality (VR)/Augmented Reality (AR) devices

Digital audio processing systems

High-resolution display controllers



Medical and Test Equipment:

Medical imaging processing devices

Laboratory analytical instruments

Patient monitoring systems

Automated test equipment



Automotive Electronics Systems:

Advanced Driver Assistance Systems (ADAS)

In-vehicle Infotainment Systems

Battery Management Systems (BMS)

Vehicle-to-Everything (V2X) Terminal Devices
