Below are the product details of the TI TCAN11625DMTRQ1 high-speed CAN transceiver, including its product description, specifications, key features, and application areas:
1. Product Description
The TCAN11625DMTRQ1 is an automotive-grade high-speed CAN FD (Flexible Data Rate) transceiver compliant with the AEC-Q100 Grade 1 standard, belonging to TI's TCAN1162x-Q1 series. The TCAN11625DMTRQ1 integrates System Baseboard Controller (SBC) functionality, complies with the ISO 11898-2:2016 high-speed CAN physical layer specification, and supports both traditional CAN and CAN FD protocols, with data transfer rates up to 8 Mbps. The core advantage of the TCAN11625DMTRQ1 lies in its built-in 5V/100mA LDO regulator, which can power the internal circuits of the transceiver and external loads (such as microcontrollers), and achieve intelligent power management via the INH pin, significantly reducing the standby power consumption of the entire vehicle system.
2. TCAN11625DMTRQ1 Specification Parameters:
Type: Transceiver
Protocol: CANbus
Driver/Receiver Count: 1/1
Voltage - Supply: 5.5V to 28V
Operating Temperature: -40°C to 150°C (TJ)
Mounting Type: Surface Mount, Wettable Flanks
Package/Case: 14-VDFN Bare Pad
Supplier Device Package: 14-VSON (3x4.5)
3. TCAN11625DMTRQ1 Protection Features:
±58V CAN Bus Fault Tolerance
Supports Load Dump on VSUP
IEC ESD Protection
Undervoltage and Overvoltage Protection
Thermal Shutdown Protection
TXD Dense State Timeout (TXD DTO)
TCAN11625DMTRQ1 Applications:
Advanced Driver Assistance Systems (ADAS)
Body Electronics and Lighting
Automotive Infotainment Systems and Instrument Clusters
Hybrid, Electric, and Powertrain Systems
TCAN11625DMTRQ1, with its highly integrated SBC architecture, 8Mbps CAN FD support, and automotive-grade reliability, serves as the core communication interface for ADAS and new energy vehicles. For more information about the TCAN11625DMTRQ1 or to inquire about pricing, please contact Mingjiada Electronics:
