Mingjiada Supply [Renesas] RAA2116514GNP Low Quiescent Current Integrated Switching Regulator
Product Details:
The RAA2116514GNP is a 60V, 5A, low quiescent current integrated switch-mode regulator featuring a constant on-time (COT) control system. The RAA2116514GNP supports a wide input voltage range from 4.5V to 60V and an adjustable output voltage (0.8V to maximum duty cycle * VIN). The RAA2116514GNP also features very low quiescent current, typically 10μA at 24V input. The modulation scheme employed by the RAA2116514GNP achieves high efficiency across all output load levels, particularly under light load conditions.
RAA2116514GNP Specifications:
Function: Buck
Output Configuration: Positive
Topology: Buck
Output Type: Adjustable
Number of Outputs: 1
Voltage - Input (Minimum): 4.5V
Voltage - Input (Maximum): 60V
Voltage - Output (Minimum/Fixed): 0.8V
Voltage - Output (Maximum): 60V
Current - Output: 5A
Frequency - Switching: 565kHz
Synchronous rectifier: Yes
Operating temperature: -40°C to 125°C (TJ)
Mounting type: Surface mount
Package/Case: 28-VFQFN bare pad
Supplier device package: 28-QFN (4x5)
RAA2116514GNP Product Features:
4.5V to 60V input power supply range
0.8V reference voltage with 1% accuracy
Adjustable output voltage (0.8V to Dmax*VIN)
Modulator: Constant On-Time (COT)
Low static current
Excellent line and load regulation
Optional internal or external control loop compensation
Adjustable load-dependent switching frequency
Output power good (PG) indicator
Programmable, optional fixed 2ms soft start and soft stop functionality
Programmable start-up and shutdown delay
Integrated LDO with bypass functionality for efficient operation
Comprehensive protection: Bidirectional high-side overcurrent (HSOC) and low-side current protection, output overvoltage protection (OVP) and output undervoltage protection (OUVP), input undervoltage lockout (UVLO), and over-temperature protection (OTP)
Optional 3.3V default VOUT using internal feedback
28-lead 4mm x 5mm QFN package
【Mingjiada Electronics】Long-term supply of TI (RAA2116514GNP) 60V, 5A, low static current integrated switch-mode regulator. For more information about the RAA2116514GNP product or to inquire about pricing, please visit the Mingjiada Electronics official website (www.mjdic.com) to check supply details.
