DUAL SWITCHING CONTROLLER, 500 kHz SWITCHING TI TPS51727RHAR TPS51727
| Part number | Brand | Date | QTY | Package | Remarks |
| TPS51727RHAR | TI |
14+ROHS | 9900 | QFN-40 |
Original have in stock |
SPECIFICATIONS
| Mfr Package Description | 6 X 6 MM, GREEN, PLASTIC, QFN-40 |
| Lead Free | Yes |
| EU RoHS Compliant | Yes |
| China RoHS Compliant | Yes |
| Status | ACTIVE |
| Package Shape | SQUARE |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE |
| Surface Mount | Yes |
| Terminal Form | NO LEAD |
| Terminal Pitch | 0.5000 mm |
| Terminal Finish | NICKEL PALLADIUM GOLD |
| Terminal Position | QUAD |
| Number of Functions | 1 |
| Number of Terminals | 40 |
| Package Body Material | PLASTIC/EPOXY |
| Control Mode | VOLTAGE |
| Control Technique | PULSE WIDTH MODULATION |
| Input Voltage-Nom | 5 V |
| Analog IC - Other Type | DUAL SWITCHING CONTROLLER |
| Switcher Configuration | PHASE-SHIFT |
| Input Voltage Limit-Max | 5.25 V |
| Input Voltage Limit-Min | 4.5 V |
| Switching Frequency-Max | 500 kHz |
PDF datasheet:
PHOTO:
