Mingjiada Supply TI TPS56C215RNNR——12A Synchronous SWIFT™ Buck Converter
Product Details:
The TPS56C215RNNR is a compact, single-chip 12A synchronous buck converter with adaptive on-time D-CAP3 control mode. The TPS56C215RNNR integrates low RDS(on) power MOSFETs, offering simplicity, efficiency, and minimal external components, making it ideal for space-constrained power systems. The TPS56C215RNNR is housed in a thermally enhanced 18-pin HotRod QFN package and is designed to operate within a junction temperature range of -40°C to 150°C.
TPS56C215RNNR Product Features:
Integrated 7.8mΩ and 3.2mΩ MOSFETs
Supports 12A continuous IOUT
4.5V startup (no 5.0V external bias)
Reference voltage of 0.6V ±-1% across the entire temperature range
Output voltage range from 0.6V to 5.5V
Supports ceramic output capacitors
D-CAP3™ control mode for fast transient response
Optional Forced Continuous Conduction Mode (FCCM) for narrow output voltage ripple, or automatic jump Eco-Mode for high light load efficiency
Selectable FSW of 400kHz, 800kHz, and 1.2MHz
Monotonic startup to pre-biased output
Two adjustable current limit settings with intermittent restart functionality
Optional 5V external bias for improved efficiency
Adjustable soft-start with a default soft-start time of 1ms
Operating junction temperature range from –40°C to 150°C
Compact 3.5mm × 3.5mm HotRod™ QFN package
TPS56C215RNNR Applications:
Servers, cloud computing, storage
Telecom and networking, point-of-load (POL)
IPC, factory automation, PLC, test and measurement
High-end DTV
Mingjiada Electronics has been supplying TI’s (TPS56C215RNNR) high-performance synchronous buck converter for the long term. The TPS56C215RNNR is an efficient, compact, and user-friendly power management solution suitable for providing stable and reliable power to high-performance processors, FPGAs, and various applications requiring high-density power supply.
For more information about the TPS56C215RNNR converter or to inquire about pricing, please contact Mingjiada Electronics:
QQ: 1668527835
Phone: 13410018555
Email: chen13410018555@163.com
