Supply ON Sensor ICs——Mingjiada Supply ON Image Sensors, Automotive-Grade Sensors
In the fields of industrial automation, automotive electronics, and machine vision, high-performance image sensors are core sensing components. Shenzhen Mingjiada Electronics Co., Ltd. — Long-term supplier of multiple high-performance image sensors from Onsemi, including but not limited to: AR0135CS, AR0237SR, AR0234CS, AS0149AT, etc., providing the ‘visual eyes’ for various intelligent systems.
Mingjiada Electronics supplies Onsemi image sensors:
1. Global Shutter Industrial-Grade Sensor: AR0135CS2C00SUEA0-DRBR
Core Parameters:
Resolution: 1280H × 960V (1.2 million pixels)
Pixel Size: 3.75µm × 3.75µm
Package: 63-iBGA (9 × 9 mm)
Operating Voltage: 1.8V–2.8V
Temperature Range: -30°C to 70°C
The AR0135CS2C00SUEA0-DRBR is a 1.2-megapixel (1280H × 960V) CMOS image sensor with a pixel size of 3.75μm × 3.75μm, packaged in a 63-iBGA package. It features a global shutter pixel design, with dark current reduced by 10 times compared to the previous generation and shutter efficiency improved by 4 times, making it suitable for industrial, consumer, and IoT applications.
Typical applications: 3D scanners, industrial robot arm positioning, gesture recognition devices, and IoT visual terminals.
2. Surveillance-grade high dynamic range sensor: AR0237SRSC12SHRA0-DR
Core parameters:
Resolution: 1928H × 1088V (2.1 million pixels)
Optical size: 1/2.7-inch
Frame rate: 60 fps (1080p full HD)
Package: 48-mPLCC (11.43 × 11.43 mm)
The AR0237SRSC12SHRA0-DR is a 2.1-megapixel (1928H × 1088V) sensor with a pixel size of 3μm × 3μm, packaged in a 48-pin mPLCC. It supports 60 fps full HD video and features dual conversion gain DR-PIX technology, making it ideal for surveillance applications.
Application scenarios: security cameras, traffic monitoring systems, high-definition video recorders.
3. High-speed global shutter sensor: AR0234CSSM28SUKA0-CR
Performance breakthroughs:
Resolution: 1920H × 1200V (2.3 million pixels)
Frame rate: 120 fps at full resolution (industry-leading)
Pixel size: 3μm × 3μm
Package: 83-ODCSP (5.6 × 10 mm)
The AR0234CSSM28SUKA0-CR is a 2-megapixel (1920H × 1200V) global shutter sensor with a pixel size of 3μm × 3μm, supporting high-speed acquisition at 120 fps. It uses an 83-pin ODCSP package and is suitable for applications such as scanners, gesture recognition, and machine vision.
Application areas: high-speed industrial inspection (e.g., PCB defect scanning), AR/VR positioning and tracking, biometric recognition (iris/fingerprint).
4. Automotive-grade HDR sensor: AS0149ATSC00XUEA1-DPBR2
Automotive-grade design:
Resolution: 1312H × 986V (1.3 million pixels)
Dynamic range: >120dB HDR (supports overexposure mode)
Pixel Technology: 3µm BSI Back-illuminated
Package: IBGA-89
AS0149ATSC00XUEA1-DPBR2 is a 1.3-megapixel automotive-grade sensor featuring BSI pixel technology, supporting >120dB HDR and 3.0μm pixel size. Packaged in IBGA-89, it is primarily used in automotive rear-view cameras and ADAS systems.
Typical applications: automotive rear-view cameras (RVC), surround-view systems (SVM), and ADAS front-view modules.
For more information about Onsemi's image sensors or to inquire about specific model prices, please contact Mingjiada:
QQ: 1668527835
Phone: 13410018555
Email: chen13410018555@163.com
