AD ADP1190ACBZ ADP1190 Integrated 500 mA Load Switch with Quad Signal Switch
| Part number | Brand | Date | QTY | Package | Remarks |
ADP1190ACBZ |
AD |
14+ROHS | 9900 | WLCSP |
Original have in stock |
PDF datasheet:
FEATURES
Low input voltage range: 1.4 V to 3.6 V
Power switch: low RDSON of 60 mΩ at 3.6 V, with active discharge
4 normally open SPST signal switches: RDSON of 2 Ω at 1.8 V with active pull-down on one side
500 mA continuous operating current
Built-in level shift for control logic that can be operated by 1.2 V logic
Ultralow shutdown current: <0.7 μA
Ultrasmall 1.2 mm × 1.6 mm × 0.5 mm, 12-ball, 0.4 mm pitch WLCSP
| Datasheets | ADP1190 |
|---|---|
| Standard Package | 1 |
| Category | Integrated Circuits (ICs) |
| Family | PMIC - Power Distribution Switches |
| Series | - |
| Packaging | Cut Tape (CT) |
| Type | High Side Switch |
| Number of Outputs | 5 |
| Rds (On) | - |
| Internal Switch(s) | Yes |
| Current Limit | 1A |
| Voltage - Input | 1.4 ~ 3.6 V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 12-UFBGA, WLCSP |
| Supplier Device Package | 12-WLCSP (1.20x1.60) |
| Dynamic Catalog | High Side Switch |
| Other Names | ADP1190ACBZ-R7CT |
