The MP8853GQ is a high-efficiency synchronous step-down converter launched by (MPS), featuring an I2C interface and supporting dynamic adjustment of output voltage and current protection parameters. Its technical parameters are as follows:
Product type: Switching voltage regulator
Topological structure: Buck
Output voltage: 600 mV to 5.5 V
Output current: 4 A
Number of Output terminals: 1 Output
Input voltage - minimum value: 2.85V
Input voltage - maximum value: 18 V
Static current: 1.6 mA
Switching frequency: 400 kHz to 600 kHz
Minimum operating temperature: -40 ° C
Maximum operating temperature: + 125 ° C
Installation style: SMD/SMT
Packaging/Cabinet: QFN-14
Development Kit: EVL8853-Q-00A
Load regulation: 3%
Shutdown
Power supply voltage - minimum: 2.85V
For details
The MP8853GQ is a high-frequency, synchronous, rectifier, step-down switching mode converter with an I2C control interface. It offers a fully integrated solution that can achieve a continuous output current (IOUT) of up to 4A and has excellent load and linear regulation over a wide input voltage (VIN) power supply range.
The output voltage (VOUT) of the MP8853GQ can be controlled in real time through the I2C serial interface. The reference voltage (VREF) can also be adjusted in steps of 4mV between 0.6V and 1.108V. In addition, the VOUT slope, switching frequency (fSW), current limit, hiccup/lock protection, enable (EN), and energy-saving mode (PSM) can also be selected through the I2C interface.
The MP8853GQ adopts constant on-time (COT) control to provide a fast transient response and indicates whether VOUT is within the nominal range through the open-drain normal (PG) pin. Its comprehensive protection functions include overvoltage protection (OVP), overcurrent protection (OCP), and over-temperature shutdown protection. The MP8853GQ is packaged in QFN-14 (3mmx3mm).
Key features
A wide operating input voltage (VIN) range of 2.85V to 18V
4A Continuous output current (IOUT)
1% internal reference accuracy
The reference voltage (VREF) can be configured within the range of 0.6V to 1.108V through I²C, with a step size of 4mV and slope control
Default forced pulse width modulation (PWM) mode
The pulse frequency modulation (PFM)/PWM mode can be selected through I²C
The switching frequency (fSW) and current limit can be adjusted through I²C
16 optional I²C addresses
Internal Soft Start (SS
The leakage power supply is normal (PG) indicator
Output Overvoltage protection (OVP
Hiccup/Lock Mode Overcurrent Protection (OCP)
The output voltage (VOUT) can be adjusted between 0.6V and 5.5V through the FB pin.
It is packaged in QFN-14 (3mmx3mm)
The performance can be optimized by adopting MPS MPL-AL series inductors
Typical applications
The MP8853GQ chip is often used in industrial equipment, consumer electronics and communication infrastructure that require dynamic voltage regulation, such as PoE power supply systems and USB charging modules.
