【 In Stock 】 DP83848CVVX 10/100Mbps Ethernet PHY transceiver supporting SNI interface and JTAG

 The DP83848CVVX is a 10/100Mbps Ethernet PHY transceiver launched by TI that supports SNI interface and JTAG and has a commercial-grade temperature range. It features the following core characteristics:

Multiple temperature ranges: from -40 °C to +105°C

Low-power 3.3V, 0.18µm CMOS technology

Low power consumption: < 270mW (typical value

3.3V MAC interface

Auto-MDIX, for 10/100 MB /s

Energy detection mode

25MHz clock output

SNI interface (configurable

RMII 1.2 interface (configurable)

MII Serial Management Interface (MDC and MDIO

IEEE 802.3MII

IEEE 802.3 Auto-Negotiation and Parallel Detection

IEEE 802.3ENDEC 10BASE-T transceiver and filter

IEEE 802.3PCS 100BASE-TX transceiver and filter

IEEE 1149.1 JTAG

Integrated TP-PMD compliant with ANSI X3.263 standard

A physical sublayer with adaptive equalization and baseline drift compensation functions

Error-free operation, with a distance of up to 150 meters

Programmable leds for linking, 10/100Mb/s mode, activity, duplex and collision detection

A single register provides access to all PHY states

10/100Mb/s data packet BIST (Built-in Self-check)

Overview

The DP83848CVVX 10/100Mb/s Ethernet PHY is specifically designed for applications requiring Ethernet connections, and its temperature performance exceeds the typical industrial temperature range. The DP83848CVVX is a highly reliable, feature-rich and robust device that complies with the IEEE 802.3 standard and is suitable for a wide range of temperatures (from extreme temperatures to commercial temperatures). The DP83848CVVX is highly suitable for harsh environments such as automotive/transportation, wireless remote base stations, and industrial control applications.

The DP83848CVVX offers the option of RMII or MII interfaces to maximize the flexibility of MPU selection and provides enhanced ESD protection, all of which are housed in a 48-pin package.

Typical applications

Automobile transportation

Industrial control and factory automation

General Embedded applications

Basic parameters

Type: Transceiver

Protocol: Ethernet

Number of drivers/receivers: 1/1

Duplex: -

Data rate: -

Voltage - Power supply: 3V to 3.6V

Operating temperature: 0°C to 70°C

Installation type: Surface mount type

Packaging/Housing: 48-LQFP
