TI TMS320F2811PBKQ IC MCU 32BIT 256KB FLASH 128LQFP
| Part number |
Brand |
Date |
QTY |
Package |
Remarks |
|
TI
|
13+ROHS |
9900 |
LQFP128 |
Original have in stock
|
PDF datasheet:
Datasheet:
| Datasheets |
TMS320F2810-12, TMS320C2810-12 Data Manual
|
| Product Photos |
128-LQFP
|
| Product Training Modules |
Microcontrollers: ControlSUITE - Comprehensive software for the entire design process
Motor Signal Chain Overview
TPS75005 Single IC Power for C2000 MCU
Intro to Timers and Clocks
|
| Design Resources |
Create your power design now with TI’s WEBENCH® Designer
|
| PCN Packaging |
14x14x1.4 LQFP Tray Update 26/Sep/2013
|
| Manufacturer Product Page |
TMS320F2811PBKQ Specifications
|
| Standard Package |
90 |
| Category |
Integrated Circuits (ICs) |
| Family |
Embedded - Microcontrollers |
| Series |
C2000™ C28x Fixed-Point |
| Packaging |
Tray |
| Core Processor |
C28x |
| Core Size |
32-Bit |
| Speed |
150MHz |
| Connectivity |
CAN, McBSP, SCI, SPI, UART/USART |
| Peripherals |
DMA, POR, PWM, WDT |
| Number of I/O |
56 |
| Program Memory Size |
256KB (128K x 16) |
| Program Memory Type |
FLASH |
| EEPROM Size |
- |
| RAM Size |
18K x 16 |
| Voltage - Supply (Vcc/Vdd) |
1.81 V ~ 2 V |
| Data Converters |
A/D 16x12b |
| Oscillator Type |
Internal |
| Operating Temperature |
-40°C ~ 125°C |
| Package / Case |
128-LQFP |
| For Use With |
701902-ND - EMULATOR C2000 SRS XDS510LC JTAG
296-31413-ND - XDS560 CLASS HIGH SPEED EMULATOR
296-23041-ND - EZ-DSP STARTER KIT FOR F2812
296-22655-ND - BUNDLE DEV F2812 W/USB EM & CORD
296-23002-ND - KIT START EZDSP FOR F2812 SOCKET
296-23055-ND - EZ-DSP STARTER KIT FOR F2812
296-23043-ND - BLACKHAWK XDS560 USB EMULATOR
296-22652-ND - BUNDLE DEV F2812 W/USB EMULATOR
|
| Other Names |
296-17278 |
