RFMD RFFM8502 WiFi Front End Module (FEM) MJD New in stock
Part number | Brand | Date | QTY | Package | Remarks |
RFFM8502 | RFMD | 13+ROHS | 7500 | QFN |
Original have in stock |
Product Description
The RFFM8502 provides a complete integrated solution in a single front end module (FEM) for WiFi 802.11a/n systems. The ultra-small form factor and integrated matching minimizes the layout area in the customer's application and greatly reduces the number of external components. This simplifies the total front end solution by reducing the bill of materials, system footprint, and manufacturability cost. The RFFM8502 integrates a power amplifier (PA), single pole double throw switch (SP2T), LNA with bypass, and a power detector coupler for improved accuracy. The device is provided in a 2.5mm x 2.5mm x 0.45mm, 16-pin QFN package. This module meets or exceeds the RF front end needs of IEEE 802.11a/n WiFi RF systems.
Features
POUT= 17.5dBm, 11a, OFDM at 2.5% EVM
Voltage Range 3.0V to 4.8V
Input and Output Matched to 50W
Integrated 5GHz PA, SP2T, Switch, LNA, and PDET
Low Height Package, Suited for SiP and CoB Designs
Applications
Cellular Handsets
Mobile Devices
Tablets
Consumer Electronics
Gaming
Netbooks/Notebooks
TV/Monitors/Video
