TI SN74HC04DR IC HEX INVERTER 14-SOIC
| Part number | Brand | Date | QTY | Package | Remarks |
| SN74HC04DR | TI | 14+ROHS | 7500 | SOP-14 |
Original have in stock |
FEATURES
• Wide Operating Voltage Range of 2 V to 6 V
• Outputs Can Drive Up To 10 LSTTL Loads
• Low Power Consumption, 20-mA Max ICC
• Typical tpd = 8 ns
• ±4-mA Output Drive at 5 V
• Low Input Current of 1 mA Max
| Datasheets | SN74HC04DR  |
|---|---|
| Packaging | Digi-Reel® |
| Logic Type | Inverter |
| Number of Circuits | 6 |
| Number of Inputs | 6 |
| Features | - |
| Voltage - Supply | 2 V ~ 6 V |
| Current - Quiescent (Max) | 2µA |
| Current - Output High, Low | 5.2mA, 5.2mA |
| Logic Level - Low | 0.5 V ~ 1.8 V |
| Logic Level - High | 1.5 V ~ 4.2 V |
| Max Propagation Delay @ V, Max CL | 16ns @ 6V, 50pF |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 14-SOIC |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) |
Picture：
