AD ADP1190 Integrated 500 mA Load Switch with Quad Signal Switch

 AD ADP1190  ADP1190ACBZ Integrated 500 mA Load Switch with Quad Signal Switch

ADP1190 PDF:

FEATURES

Low input voltage range: 1.4 V to 3.6 V

Power switch: low RDSON of 60 mΩ at 3.6 V, with active discharge

4 normally open SPST signal switches: RDSON of 2 Ω at 1.8 V with active pull-down on one side

500 mA continuous operating current

Built-in level shift for control logic that can be operated by 1.2 V logic

Ultralow shutdown current: <0.7 μA

Ultrasmall 1.2 mm × 1.6 mm × 0.5 mm, 12-ball, 0.4 mm pitch WLCSP

APPLICATIONS

Mobile phones

SIM card disconnect switches

Digital cameras and audio devices

Portable and battery-powered equipment
