NXP LPC2364FET100 Single-chip 16-bit/32-bit microcontrollers

 NXP LPC2364FET100 Single-chip 16-bit/32-bit microcontrollers; up to 512 kB flash with ISP/IAP, Ethernet, USB 2.0, CAN, and 10-bit ADC/DAC

Features and benefits

ARM7TDMI-S processor, running at up to 72 MHz

Up to 512 kB on-chip flash program memory with In-System Programming (ISP) and

In-Application Programming (IAP) capabilities. Flash program memory is on the ARM

local bus for high performance CPU access.

8 kB/32 kB of SRAM on the ARM local bus for high performance CPU access.

16 kB SRAM for Ethernet interface. Can also be used as general purpose SRAM.

8 kB SRAM for general purpose DMA use also accessible by the USB.

Dual Advanced High-performance Bus (AHB) system that provides for simultaneous

Ethernet DMA, USB DMA, and program execution from on-chip flash with no

contention between those functions. A bus bridge allows the Ethernet DMA to access the other AHB subsystem.

Advanced Vectored Interrupt Controller (VIC), supporting up to 32 vectored interrupts.

General Purpose DMA controller (GPDMA) on AHB that can be used with the SSP

serial interfaces, the I2S port, and the Secure Digital/MultiMediaCard (SD/MMC) card

port, as well as for memory-to-memory transfers.

Specification

Datasheets	LPC2364FET100
Core Processor	ARM7®
Core Size	16/32-Bit
Speed	72MHz
Connectivity	CAN, Ethernet, I²C, Microwire, SPI, SSI, SSP, UART/USART, USB
Peripherals	Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT
Number of I/O	70
Program Memory Size	128KB (128K x 8)
Program Memory Type	FLASH
EEPROM Size	-
RAM Size	34K x 8
Voltage - Supply (Vcc/Vdd)	3 V ~ 3.6 V
Data Converters	A/D 6x10b; D/A 1x10b
Oscillator Type	Internal
Operating Temperature	-40°C ~ 85°C
Package / Case	100-TFBGA
