NXP TD1611ALF TD1611 Tuner module for digital terrestrial
Part number | Brand | Date | QTY | Package | Remarks |
TD1611ALF | NXP | 14+ROHS | 7500 | DIP |
Original have in stock |
Features
• Highly integrated RF-module, 3-band tuner plus active loopthrough
• +5V supply voltage only; no external tuning voltage required
• Tuners for horizontal and vertical mounting available
• Option with DC – power output through input connector (e.g. indoor antenna supply)
• Tuners comply with relevant CENELEC standards with regard to requirements
concerning signal handling capability and immunity
• Superior low noise and high sensitivity performance
• RF-in to RF-out loopthrough amplifiers
• Low noise and excellent linearity
• Full VHF to UHF frequency range coverage
• Standard connectors for in- and output e.g. IEC, F-connector, RCA
• High performance and cost effective single conversion tuner
• I2C programmable
• 400kHz Bus compliant
• Fast PLL tuning speed (programmable step size e.g. 62.5kHz and 166.67kHz)
• Tuner internal gain control loop with selectable TakeOverPoint settings via I2C Bus
• External gain control possible with internal loop disabled
• 4.0V (max. gain) to 0V (min. gain) gain control voltage
• Flat overall frequency response
• High PLL loop bandwidth which ensures very low oscillator phase noise
• 4 MHz crystal reference frequency output
• SAW-filter and IF-amplifier included
• Switchable 7/8 MHz SAW filter
• Fixed 8 MHZ SAW filter
• IF-amplification controllable over a wide range
