Infineon TLE4946-2K TLE4946 IC HALL EFFECT LATCH SC59
| Part number | Brand | Date | QTY | Package | Remarks |
| TLE4946-2K | Infineon | 14+ROHS | 7500 | SOT-23 |
Original have in stock |
Features
• 2.7 V to 24 V supply voltage operation
• Operation from unregulated power supply
• High sensitivity and high stability of the magnetic switching points
• High resistance to mechanical stress by active error compensation
• Reverse battery protection (– 18V)
• Superior temperature stability
• Peak temperatures up to 195°C without damage
• Low jitter (typ. 1 µs)
• High ESD performance (± 4kV HBM)
• Digital output signal
• SMD package SC59
| Datasheets | TLE4946-2K |
|---|---|
| Sensing Range | 2mT Trip, -2mT Release |
| Type | Bipolar Latch |
| Voltage - Supply | 2.7 V ~ 18 V |
| Current - Supply | 4mA |
| Current - Output (Max) | 20mA |
| Output Type | Digital, Open Collector |
| Features | Regulated Voltage |
| Operating Temperature | -40°C ~ 150°C |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
