NXP LPC2132FBD64 LPC2132 Single-chip 16/32-bit microcontrollers

NXP LPC2132FBD64  LPC2132 Single-chip 16/32-bit microcontrollers

Key features

■ 16/32-bit ARM7TDMI-S microcontroller in a tiny LQFP64 package.

■ 8/16/32 kB of on-chip static RAM and 32/64/128/256/512 kB of on-chip Flash program

memory. 128 bit wide interface/accelerator enables high speed 60 MHz operation.

■ In-System/In-Application Programming (ISP/IAP) via on-chip boot-loader software.

Single Flash sector or full chip erase in 400 ms and programming of 256 bytes in 1 ms.

■ EmbeddedICE RT and Embedded Trace interfaces offer real-time debugging with the

on-chip RealMonitor software and high speed tracing of instruction execution.

■ One (LPC2131/32) or two (LPC2134/36/38) 8 channel 10-bit A/D converters provides

a total of up to 16 analog inputs, with conversion times as low as 2.44 µs per channel.

■ Single 10-bit D/A converter provides variable analog output (LPC2132/34/36/38).

■ Two 32-bit timers/external event counters (with four capture and four compare

channels each), PWM unit (six outputs) and watchdog.

■ Low power Real-time clock with independent power and dedicated 32 kHz clock input.

■ Multiple serial interfaces including two UARTs (16C550), two Fast I2C-bus (400 kbit/s),

SPI and SSP with buffering and variable data length capabilities.

■ Vectored interrupt controller with configurable priorities and vector addresses.
