AD ADM202EARNZ ADM202 Line Drivers/Receivers
| Part number | Brand | Date | QTY | Package | Remarks |
| ADM202EARNZ | AD | 14+ROHS | 7500 | SOP-16 |
Original have in stock |
FEATURES
Complies with 89/336/EEC EMC directive
ESD protection to IEC1000-4-2 (801.2)
±8 kV: contact discharge
±15 kV: air-gap discharge
±15 kV: human body model
EFT fast transient/burst immunity (IEC1000-4-4)
Low EMI emissions (EN55022)
230 kbits/s data rate guaranteed
TSSOP package option
Upgrade for MAX202E, 232E, LT1181A
APPLICATIONS
General-purpose RS-232 data link
Portable instruments
PDAs
| Datasheet | ADM202EARNZ |
|---|---|
| Type | Transceiver |
| Protocol | RS232 |
| Number of Drivers/Receivers | 2/2 |
| Duplex | Full |
| Receiver Hysteresis | 650mV |
| Data Rate | 230kbps |
| Voltage - Supply | 4.5 V ~ 5.5 V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
