ON MBRS360T3G MBRS360 SCHOTTKY BARRIER RECTIFIERS
| Part number | Brand | Date | QTY | Package | Remarks |
| MBRS360T3G | ON | 14+ROHS | 7500 | DO-214 |
Original have in stock |
Features
• Small Compact Surface Mountable Package with J−Bend Leads
• Rectangular Package for Automated Handling
• Highly Stable Oxide Passivated Junction
• Excellent Ability to Withstand Reverse Avalanche Energy Transients
• Guard−Ring for Stress Protection
• NRVBS Prefix for Automotive and Other Applications Requiring
Unique Site and Control Change Requirements; AEC−Q101
Qualified and PPAP Capable
• These are Pb−Free Devices
Mechanical Characteristics
• Case: Epoxy, Molded, Epoxy Meets UL 94 V−0
• Weight: 217 mg (Approximately), SMC 95 mg (Approximately), SMB
• Finish: All External Surfaces Corrosion Resistant and Terminal Leads are Readily Solderable
• Lead and Mounting Surface Temperature for Soldering Purposes:260°C Max. for 10 Seconds
• Polarity: Notch in Plastic Body Indicates Cathode Lead
• Device Meets MSL 1 Requirements
• ESD Ratings:
♦ Machine Model, C
♦ Human Body Model, 3B
| Datasheet | MBRS360T3G |
|---|---|
| Diode Type | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 60V |
| Current - Average Rectified (Io) | 3A |
| Voltage - Forward (Vf) (Max) @ If | 740mV @ 3A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | - |
| Current - Reverse Leakage @ Vr | 150µA @ 60V |
| Capacitance @ Vr, F | - |
| Mounting Type | Surface Mount |
| Package / Case | DO-214AB, SMC |
| Supplier Device Package | SMC |
| Operating Temperature - Junction | -65°C ~ 175°C |
