NEC UPG2314T5N UPG2314 GaAs HBT INTEGRATED CIRCUIT New in stock
| Part number | Brand | Date | QTY | Package | Remarks |
| UPG2314T5N | NEC | 14+ROHS | 7500 | QFN |
Original have in stock |
FEATURES
･ Operating Frequency : fopt = 2400 to 2500MHz 2450MHz TYP.
･ Supply Voltage : VCC1,2 = 2.7 to 3.6V 3.0V TYP.
･ Control Voltage : Vcont = 0 to 3.6V 3.0V TYP.
: Vbias + Venable = 0 to 3.1V 3.0V TYP.
･ Circuit Current : ICC = 65mA TYP. @ VCC1,2 = 3.0V, Vbias + Venable = 3.0V, Vcont = 3.0V, Pin = 0dBm
･ Output Power : Pout = +20.0dBm TYP.@ VCC1,2 = 3.0V, Vbias + Venable = 3.0V, Vcont = 3.0V, Pin = 0dBm
･ Gain Control Range : GCR = 23dB TYP.@ VCC1,2 = 3.0V, Vbias + Venable = 3.0V, Vcont = 0 to 3.0V, Pin = 0dBm
･ High Efficiency : PAE = 50 TYP.
･ High-density surface mounting : 6-pin TSON package 1.5 1.5 0.37 mm
Specification：
| Datasheet
|
|
|
Mfr Package Description |
1.50 X 1.50 MM, 0.37 MM HEIGHT, LEAD FREE, PLASTIC, TSON-6 |
|
Lead Free |
Yes |
|
EU RoHS Compliant |
Yes |
|
Status |
DISCONTINUED |
|
Construction |
COMPONENT |
|
Terminal Finish |
NOT SPECIFIED |
|
Operating Temperature-Max |
85 Cel |
|
Operating Temperature-Min |
-40 Cel |
|
Input Power-Max (CW) |
10 dBm |
|
Operating Frequency-Max |
2500 MHz |
|
Operating Frequency-Min |
2400 MHz |
|
RF/Microwave Device Type |
WIDE BAND MEDIUM POWER |
