PIC16F1947-I/MR PIC16F1947 8-Bit CMOS Microcontrollers

Datasheet

PIC16F1947-I/MR

Mfr Package Description

9 X 9 MM, 0.90 MM HEIGHT, LEAD FREE, QFN-64

Lead Free

Yes

EU RoHS Compliant

Yes

China RoHS Compliant

Yes

Status

ACTIVE

Technology

CMOS

Package Shape

SQUARE

Package Style

CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

Surface Mount

Yes

Terminal Form

NO LEAD

Terminal Pitch

0.5000 mm

Terminal Finish

MATTE TIN

Terminal Position

QUAD

Number of Functions

1

Number of Terminals

64

Package Body Material

UNSPECIFIED

Temperature Grade

INDUSTRIAL

Operating Temperature-Max

85 Cel

Operating Temperature-Min

-40 Cel

Supply Voltage-Max (Vsup)

5.5 V

Supply Voltage-Min (Vsup)

2.5 V

Supply Voltage-Nom (Vsup)

3.3 V

ADC Channels

Yes

Address Bus Width

8

Bit Size

16

Clock Freq-Max (fclk)

32 MHz

External Data Bus Width

8

Microprocess IC Type

RISC MICROCONTROLLER

Number of I/O Lines

54

PWM Channels

Yes

ROM Programmability

FLASH

Speed

32 MHz
