5962-9476101MXC 5962-9476101 In-System Programmable High Density PLD

 Lattice 5962-9476101MXC 5962-9476101 In-System Programmable High Density PLD

Features

• HIGH-DENSITY PROGRAMMABLE LOGIC

— High-Speed Global Interconnect

— 4000 PLD Gates

— 48 I/O Pins, Six Dedicated Inputs

— 144 Registers

— Wide Input Gating for Fast Counters, State

Machines, Address Decoders, etc.

— Small Logic Block Size for Fast Random Logic

— Security Cell Prevents Unauthorized Copying

• HIGH PERFORMANCE E2CMOS®TECHNOLOGY

— fmax= 60 MHz Maximum Operating Frequency

— tpd= 20 ns Propagation Delay

— TTL Compatible Inputs and Outputs

— Electrically Erasable and Reprogrammable

— Non-Volatile E2

CMOS Technology

— 100% Tested

• IN-SYSTEM PROGRAMMABLE

— In-System Programmable™ (ISP™) 5-Volt Only

— Increased Manufacturing Yields, Reduced Time-toMarket, and Improved Product Quality

— Reprogram Soldered Devices for Faster Debugging

• COMBINES EASE OF USE AND THE FAST SYSTEM

SPEED OF PLDs WITH THE DENSITY AND FLEXIBILITY OF FIELD PROGRAMMABLE GATE ARRAYS

— Complete Programmable Device Can Combine Glue

Logic and Structured Designs

— Four Dedicated Clock Input Pins

— Synchronous and Asynchronous Clocks

— Flexible Pin Placement

— Optimized Global Routing Pool Provides Global

Interconnectivity

• ispDesignEXPERT™ – LOGIC COMPILER AND COMPLETE ISP DEVICE DESIGN SYSTEMS FROM HDL

SYNTHESIS THROUGH IN-SYSTEM PROGRAMMING

— Superior Quality of Results

— Tightly Integrated with Leading CAE Vendor Tools

— Productivity Enhancing Timing Analyzer, Explore

Tools, Timing Simulator and ispANALYZER™

— PC and UNIX Platforms
