ON MC33035DWR2G MC33035 Brushless DC Motor Controller
| Part number | Brand | Date | QTY | Package | Remarks |
| MC33035DWR2G | ON | 14+ROHS | 7500 | SOP-24 |
Original have in stock |
Features
• 10 to 30 V Operation
• Undervoltage Lockout
• 6.25 V Reference Capable of Supplying Sensor Power
• Fully Accessible Error Amplifier for Closed Loop Servo
Applications
• High Current Drivers Can Control External 3−Phase MOSFET Bridge
• Cycle−By−Cycle Current Limiting
• Pinned−Out Current Sense Reference
• Internal Thermal Shutdown
• Selectable 60°/300° or 120°/240° Sensor Phasings
• Can Efficiently Control Brush DC Motors with External MOSFET H−Bridge
• NCV Prefix for Automotive and Other Applications Requiring Site
and Control Changes
• Pb−Free Packages are Available
| Datasheet | MC33035DWR2G |
|---|---|
| Packaging | Tape & Reel (TR) |
| Motor Type - Stepper | - |
| Motor Type - AC, DC | Brushless DC (BLDC) |
| Function | Controller - Commutation, Direction Management |
| Output Configuration | Pre-Driver |
| Interface | Analog |
| Applications | General Purpose |
| Current - Output | - |
| Voltage - Supply | 10 V ~ 30 V |
| Voltage - Load | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 24-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 24-SOIC |
