AP3586AMTR AP3586 Single Phase Synchronous Buck PWM Controller

AP3586AMTR AP3586 Single Phase Synchronous Buck PWM Controller

Features

 • Supply Voltage: 5V/12V

• VIN Input Range: 3.3V to 12V

• 0.6V/0.8V to 82% of VIN Output Range

• Internal Reference: 0.6V/0.8V

• Simple Single-loop Control

• Voltage-mode PWM Control

• Duty Cycle: 0% to 82%

• Fast Transient Response

• 10MHz High-bandwidth Error Amplifier with 6V/µs Slew Rate

• Fixed Oscillator Frequency: 300kHz/200kHz

• Lossless, Programmable Over Current Protection (Uses Lower MOSFET RDS(ON) )

• Start-up into Pre-biased Load

• Built-in Thermal Shutdown

• Built-in Soft-start

• Over Current Protection

• Over Voltage Protection

• Under Voltage Protection • Integrated Boot Diode

 Applications

 • Subsystem Power Supplies

• PCI, AGP, Graphics Cards, Digital TV

• SSTL-2 and DDR/2/3 SDRAM Bus Termination Supply

• Cable Modems, Set Top Boxes, and DSL Modems

• Industrial Power Supplies and General Purpose Supplies
