M25P32-VMW6TG 25P32V6G 32-Mbit low voltage serial Flash memory

 M25P32-VMW6TG 25P32V6G  32-Mbit low voltage serial Flash memory

PDF Datasheet：

Features

■ 32 Mbit of Flash memory

■ 2.7 V to 3.6 V single supply voltage

■ SPI bus compatible serial interface

■ 75 MHz clock rate (maximum)

■ VPP = 9 V for Fast Program/Erase mode (optional)

■ Page Program (up to 256 bytes)

– in 0.64 ms (typical)

■ Sector Erase (512 Kbit) in 0.6 s (typical)

■ Bulk Erase:

– in 23 s (typical)

– in 17 s (typical with VPP = 9 V)

■ Deep Power-down mode 1 µA (typical)

■ Electronic Signatures

– JEDEC standard two-byte signature (2016h)

– Unique ID code (UID) +16 bytes of CFI data

– RES instruction, one-byte, signature (15h), for backward compatibility

■ Hardware Write Protection of the memory area selected using the BP0, BP1 and BP2 bits

■ More than 100 000 Erase/Program cycles per sector

■ More than 20 year data retention

■ Packages

– ECOPACK® (RoHS compliant)
