IR2155 SELF-OSCILLATING HALF-BRIDGE DRIVER
| Part number | Brand | Date | QTY | Package | Remarks |
| IR2155 | IR | 14+ROHS | 7500 | DIP-8 |
Original have in stock |
Specification：
| PDF Datasheet | IR2155  |
|---|---|
| Packaging | Tube |
| Configuration | Half Bridge |
| Input Type | Self Oscillating |
| Delay Time | - |
| Current - Peak | 250mA |
| Number of Configurations | 1 |
| Number of Outputs | 2 |
| High Side Voltage - Max (Bootstrap) | 600V |
| Voltage - Supply | 10 V ~ 20 V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | 8-DIP |
Picture：
MJD is a corporation which engaged in agency electronic components. MJD Through seventeen years unrimitting efforts, aspire to provide our customers with world-leading products and service. Nowalready became a one of the most famous electronic components distributor in China.
