AKM AK2365 dPMR Filterless IF LSI

AKM

AK2365

AK2365 date sheet

Product category

dPMR Filterless IF LSI

Application

eliminate E to J type ceramic filters,quadrature discriminator,and other external

Description

Low operating voltage:VDD=2.6 to 5.5V

Wide operating temperature: Ta=-40 to 85 C

High sensitivity:-102 dBm at 12dB SINAD

Built-in PGA and 2nd Mixer

Local frequency: 45.9MHz,50.4MHz,57.6MHz(Triple of 15.3,16.8 and 19.2MHz)

Built-in programmable AGC+BPF circuits corresponding to E to J type ceramic filters

Built-in PLL FM detector

RSSI function

Built-in noise squelch circuits

Low consumption current:6mA

Compact plastic packaging: 32-pin QFNJ(4.0x4.0x0.75mm,0.4mm pitch)
