AKM AK4386ET 100dB 96kHz 24-Bit 2ch DAC

AKM

AK4386ET

AK4386ET date sheet

Product category

100dB 96kHz 24-Bit 2ch DAC

Application

portable audio system like MP3 and the home audio systems like STB and TV

Description

Sampling Rate: 8kHz ∼ 96kHz

24-Bit 8 times FIR Digital Filter

SCF with high tolerance to clock jitter

Single-ended output buffer

Digital de-emphasis for 44.1kHz sampling

I/F Format: 24-Bit MSB justified, 16/24-Bit LSB justified, I2 S Compatible

Master Clock:

512/768/1024/1536fs for Half Speed (8kHz ∼ 24kHz)

256/384/512/768fs for Normal Speed (8kHz ∼ 48kHz)

128/192/256/384fs for Double Speed (48kHz ∼ 96kHz)

CMOS Input Level

THD+N: −86dB

DR, S/N: 100dB(@VDD=3.0V)

Power Supply: 2.2 to 3.6V

Ta = −20 ∼ 85°C (ET), −40 ∼ 85°C (VT)

16pin TSSOP
