NXP IP4359CX4 Dual channel low capacitance

NXP

IP4359CX4

IP4359CX4 date sheet

Product category

Dual channel low capacitance high performance ESD protection

Application

High-speed interface ESD protection such as USB 2.0, HDMI, DVI etc.

Interfaces with special requirements on low capacitive ESD protection

Interfaces requiring separation of the positive clamping voltage/current path

Description

Pbfree,RoHScompliantandfreeofhalogenandantimony(DarkGreencompliant)

2ultralowinputcapacityrail-to-railESDprotectiondiodeswithC(I/O-GND)=1.3pF

Rdyn=0.45Ω

IntegratedESDprotectionwithstanding±15kVcontactdischargeand>±15kVair

discharge,farexceedingIEC61000-4-2level4

Standardheightversion(0.61mm)availableasIP4359CX4/LF

Reducedheightversion(maximumheightof0.5mm)availableas

IP4359CX4/LF-H500

2×2solderballWLCSPwith0.4mmpitch
