Manufacturer Part |
|
|
Product Category |
10-Bit, 40 MSPS, 3 V, 74 mW A/D Converter |
|
Application |
CCD imaging |
|
Datasheet |
Details
|
Description |
|
Image Features CMOS 10-Bit, 40 MSPS sampling A/D converter Power dissipation: 74 mW (3 V supply, 40 MSPS) 17 mW (3 V supply, 5 MSPS) Operation between 2.7 V and 3.6 V supply Differential nonlinearity: −0.25 LSB Power-down (standby) mode, 0.65 mW ENOB: 9.55 @ fIN = 20 MHz Out-of-range indicator Adjustable on-chip voltage reference IF undersampling up to fIN = 130 MHz Input range: 1 V to 2 V p-p differential or single-ended Adjustable power consumption Internal clamp circuit APPLICATIONS CCD imaging Video Portable instrumentation IF and baseband communications Cable modems Medical ultrasound |
