MAXIM MAX3349E MAX3349EEBE USB 2.0 Transceiver

Description


Features

±15kV ESD HBM Protection on D+ and D-

UART Mode Routes External UART Signals to D+/D-

Internal Linear Regulator Allows Direct Powering

from the USB Cable

Separate Voltage Input for UART

Transmitter/Receiver (VUART)

Internal 1.5kΩ Pullup Resistor on D+ Controlled

by Enumerate Input

Internal Series Termination Resistors on D+ and D-

Complies with USB Specification Revision 2.0,

Full-Speed 12Mbps Operation

Built-In Level Shifting Down to +1.4V, Ensuring

Compatibility with Low-Voltage ASICs

VBUS Detection

Combined VP and VM Inputs/Outputs

No Power-Supply Sequencing Required

Available in 16-Bump UCSP (2mm x 2mm) Package
