Manufacturer Part |
|
|
Product Category |
3.3V-Powered, ±15kV ESD-Protected, 12Mbps and Slew-Rate-Limited True RS-485/RS-422 Transceivers |
|
Application |
Telecommunications Industrial-Control Local Area Networks Transceivers for EMI-Sensitive Applications Integrated Services Digital Networks Packet Switching |
|
Datasheet |
Details
|
Description |
|
Image Features ESD Protection for RS-485 I/O Pins ±15kV—Human Body Model ±8kV—IEC 1000-4-2, Contact Discharge ±15kV—IEC 1000-4-2, Air-Gap Discharge Operate from a Single +3.3V Supply— No Charge Pump Required Interoperable with +5V Logic Guaranteed 12Mbps Data Rate (MAX3485E/MAX3490E/MAX3491E) Slew-Rate Limited for Errorless Data Transmission (MAX3483E/MAX3488E) 2nA Low-Current Shutdown Mode (MAX3483E/MAX3485E/MAX3486E/MAX3491E) -7V to +12V Common-Mode Input Voltage Range Full-Duplex and Half-Duplex Versions Available Industry-Standard 75176 Pinout (MAX3483E/MAX3485E/MAX3486E) Current-Limiting and Thermal Shutdown for Driver Overload Protection Compatibility with Low-Voltage ASICs VBUS Detection Combined VP and VM Inputs/Outputs No Power-Supply Sequencing Required Available in 16-Bump UCSP (2mm x 2mm) Package |
