MAXIM MAX829 MAX829EUK Switched Capacitor Voltage Inverters

Description


Features

5-Pin SOT23-5 Package

95% Voltage Conversion Efficiency

Inverts Input Supply Voltage

60µA Quiescent Current (MAX828)

+1.5V to +5.5V Input Voltage Range

Requires Only Two Capacitors

25mA Output Current

 APPLICATIONS

Small LCD Panels

Cell Phones

Medical Instruments

Handy-Terminals, PDAs

Battery-Operated Equipment
